2BB mono Solar Cell for Solar Panel 100W 125*125mm

Toupdate:2016-09-14

Immediately consult

Service support

分享至:

Product Description

   2BB Poly Solar Cell for Solar Panel 100W 125*125mm

Physical Characteristics

Thickness:200μm±20μm / 180μm±20μm

Dimension:156.75*156.75mm±0.25mm

1.PID-free.
2.Both efficiency and Impp sorting to enhance module output power.
3.100% in-line inspection of optiCal,Irev (<2.0A @-10V, <2.5a and="">10 ohm).
4.Long term efficiency sability and excellent reliability.
5.ISO 9001,ISO14001 and OHSAS 18001 certified.



                  Front(-)                                                                                 Back(+)

blue nitride silicon antireflection coating                          Aluminum back surface field

               1.5mm wide bus bars                                               2.0mm wide soldering pads



High conversion efficiency resulting in superior power output performance.

Outstanding power output even in low light or high temperature conditions.

Optimized design for ease of soldering and lamination.

Long-term stability, reliability and performance .

Low breakage rate.

Output power tolerance of   +/- 3%.



156*156MM 3BB solar cell picture showing:
